Serve For Real Test
Serve For Real Test
 |
| Place of Origin: | China |
| Brand Name: | SRI |
| Certification: | ISO 9001:2000 |
| Model Number: | TSZ-C |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | 10000USD/set |
| Packaging Details: | Standard exporting package |
| Delivery Time: | 5-10 working days |
| Payment Terms: | T/T, L/C, PAYPAL |
| Supply Ability: | 50 sets/month |
| Power: | Electronic | Usage: | Soil Test |
|---|---|---|---|
| High Light: | soil triaxial tester,soil testing instruments,triaxial test machine |
||
10/30/60KN Full Automatic triaxial tester
Description
This series full automatic triaxial apparatus adopts the latest technology, which integrates the mechanical, electronic, automatic control, transducer and computer technology, it achieves multi-purpose. The general configuration can do normal stress, strain test like UU, CU, CD and other compression & shearing test, if equipped with different testing container and control module, it can also do test such as KO consolidation, static lateral pressure coefficient, multi stress way triaxial, tensile, resilience modulus, bearing ratio. If equipped with consolidation module, it also can do incremental loading, continuous loading test. If equipped with vibration module, it also can do full automatic vibration triaxial test. The whole process will be controlled by computer.
Specifications
Specimen size:
TSZ-C1: Φ39.1mm x 80mm
TSZ-C2: Φ39.1mm x 80mm. Φ61.8mm x 125mm
TSZ-C3: Φ39.1mm x 80mm. Φ61.8mm x 125mm. Φ101mm x 200mm
Confining pressure: 0-2MPa
Back pressure: 0-2MPa;
Volume change:
TSZ-C1/ C2: 0-50ml; TSZ-C3: 0-100ml
Axial loading:
TSZ-C1: 0-10KN; TSZ-C2: 0-30KN; TSZ-C3: 0-60KN
Pore pressure: 0-2MPa
Shearing rate: 0.0001mm/min-2.4mm/min; 0.0001mm/min-4.8mm/min
