| Place of Origin: | China |
| Brand Name: | SRI |
| Certification: | ISO 9001 |
| Model Number: | FZ-DL500 |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | 2000USD |
| Packaging Details: | Polywood case |
| Delivery Time: | 7 working days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100set/month |
| Test Standards: | GB/T9997 GB/T14337 ISO5079 ISO11566 | Test Material: | Fiber, Filament |
|---|
Standards: GB/T9997 GB/T14337 ISO5079 ISO11566
This tester is Suitable for tensile strength testing of kinds of fiber and ultra-slim metal filament
Specifications
1.Max test load: 100cn 300cn 500cn
2.Loading force accuracy: 0.02%(F.S)
3.Loading resolution: 0.01cn
4.Max elongation test range: 400mm
5.Stretch measurement resolution: 0.01mm
6.Zero point drift: ≤0.2%(F.S)
7.Low gripper down speed: 1~199mm/min
8.Decline rate deviation: ≤1%
9.Low gripper up rate: 0~200m/min
10.Pretension: 0.1cn,0.2cn,0.3cn,0.4cn,0.5cn
11.Power supply: AC220V±10%,50Hz
12.Overall size: 450×400×700
13.Net weight: 30Kg
