Serve For Real Test
Serve For Real Test
 |
| Place of Origin: | China |
| Brand Name: | SRI |
| Certification: | ISO 9001 |
| Model Number: | FZ-091L |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | 2000USD |
| Packaging Details: | Polywood case |
| Delivery Time: | 7 working days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 50set/month |
| Test Standards: | ASTM D4964 BS 4592 | Test Material: | Socks, Knitted Underwear, Woven Fabrics |
|---|
This elastic testing machine is used to measure the elastic properties of various socks, knitted underwear, woven fabrics, spandex yarns, spandex cored wires, slings and elastic bands.
Standards
FZ / T01034 FZ / T01062 ASTM D4964 BS 4592 etc.
Specifications
| Model | FZ-09105 | FZ-09110 | FZ-09120 | FZ-09150 |
| Measure range | 0-50N | 0-100N | 0-200N | 0-500N |
| Min resolution | 0.02N | 0.05N | 0.1N |
0.5N |
2. Load accuracy: ≤ ± 0.02% F.S
3. Data sampling frequency: 1000 times / second
4. Stretching speed: 10 ~1000mm / min adjustable
5. Maximum extension: 800mm
6. Elongation resolution: 0.01mm
7. Data storage capacity: ≥1000 times (test machine data storage capacity), and can be browsed at any time
8. Pre-tension: 0-150cN adjustable
9. Power: AC 220V 50HZ 200W
Dimensions: 520 mm × 400 mm × 1600 mm (L × W × H)
