Serve For Real Test
Serve For Real Test
 |
| Place of Origin: | China |
| Brand Name: | SRI |
| Certification: | ISO 9001 |
| Model Number: | FZ-815 |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | 1000USD |
| Packaging Details: | Polywood case |
| Delivery Time: | 7 working days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 50set/month |
| Test Standards: | EN71-2 ISO6941-2003 | Test Material: | Fabric Toys |
|---|
Standards GB1474 GB6675 EN71-2 ISO6941-2003
This equipment is used to test the burning performance of children's clothing or toys and their accessories, and evaluate the burning speed and time of toys.
Specifications
1. Burner: The throat diameter of the burner Φ0.19 + 0.02mm, the length is 75mm, and the mixing vent is Φ1.7, air inlet is 4XΦ4 mm
2. Flame height: adjustable within the range of 20mm ± 2mm ~ 40mm ± 3mm
3. Ignition time: 0 ~ 99S can be set
4. Burning time: 0-9999S
5. Flame test angle: 90 °, 45 ° degrees optional.
6. Sample fixture:
a. U-shaped test clip internal size: 600mm × 80mm according to GB6675-2003
b. Nail plate sample holder: 500mm × 800mm Nails: φ5 × 75mm 80 pieces
7. Power supply: AC220V 50Hz
8. Shape: 850 × 650 × 1050mm
9. Weight: 40kg
