Serve For Real Test
Serve For Real Test
 |
| Place of Origin: | Jiangsu |
| Brand Name: | SRI |
| Certification: | ISO9001-2008 |
| Model Number: | FZ-031W |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | 3000USD |
| Packaging Details: | meet standard packing requiments |
| Delivery Time: | 7 working days |
| Payment Terms: | TT/Paypal/Western Union |
| Supply Ability: | 200 set/month |
| Power Supply: | AC220V, 50HZ, 200W | Overall Dimension: | 500×500×1200mm |
|---|---|---|---|
| Net Weight: | 100kg | Standards: | ASTM, ISO, GB |
Application scope
For ball bursting strength and expansion ratio test of cotton fabrics, elastic webbing and socks gloves.
Standards
GB/T 19976, FZ/T 01030, FZ/T 60019, ASTM D 3787, ASTM D 6796
Features
Constant rate elongation (CRE) principle, microcomputer control
Computer operation, report, curve, graphical display, direct in sight
DC servo drive, wide range speed setup
Imported high quality transducer
Tailor made according to customer requirements
Aluminum alloy enclosure nice in appearance
Technical Specifications
Testing range:2500N (1%~100%F.S)
Testing accuracy: ±0.2%F.S
Test rate range: 5-500mm/min
Ball bursting max fall stroke: 120mm
Clamp diameter: 45mm (Φ25mm optional)
Ball diameter: 25mm(Φ20mm Φ38mm optional)
Power supply: AC220V, 50Hz, 0.6KW
Overall size: 500×500×1200mm
Net weight: 100kg
