| Place of Origin: | China mainland |
| Brand Name: | SRI |
| Certification: | IP68 Exd IIC T6 Gb |
| Model Number: | BX650Ex |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | 300-1000USD |
| Packaging Details: | Wooden case |
| Delivery Time: | 7 working days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 300set per month |
| Protection Degree: | IP68 | Material: | Stainless Steel |
|---|---|---|---|
| Installation: | Wall Mount, Base, Fixed Bracket | Application: | Industry Online Monitoring |
| Cusomized: | Yes | Power Supply: | 220VAC |
Introduction
The explosion-proof terminal box is a mature explosion-proof monitoring device. A certain volume of electrical equipment can be installed inside. The stainless steel shell can provide strong protection. It is widely used in environments with flammable and explosive gases.
Features
-Made of stainless steel
-Can install other electrical equipment of a certain size
-With 6 outlet holes
-Protection class IP68
-Indoor and outdoor installation, all-weather use
Specifications
Input voltage 220VAC
Input voltage range ±10%
Working current ＜300mA
Material Stainless steel 304 or 316L
Protection class IP68
Internal free space 240(L) x 210(W) x 100(H) mm
Net Weight 15.8Kg / 12Kg
Shipping weight 19Kg / 15Kg
Number of outlet holes 6
Outlet specifications G-3/4";
