| Place of Origin: | China |
| Brand Name: | SRI |
| Certification: | ISO 9001 2008 |
| Model Number: | TYSX-2 |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | 1000USD |
| Packaging Details: | Carton case |
| Delivery Time: | 10 WORKING DAYS |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 50SET/month |
| PC Connection: | Optional | Printer: | Optional |
|---|---|---|---|
| Sensor: | Digital Displacement Sensor | Indication Accuracy: | 0.01mm |
Features
1. Advanced digital displacement sensor, higher accurately.
2. Stainless steel cone tip, not easy to wear.
3. Standard cone and connecting rod are easy to disassemble and assemble, which is convenient to check the quality
4. Optional configuration printer can output directly.
5. Indication accuracy: 0.01mm.
6. LCD display, automatic measurement, automatic display, automatic storage.
7. RS232 interface, print or computer connection optional
Technical specifications
1. Minimum indexing value: 0.01mm
2. Maximum measurement range: 40mm
3. Cone and connecting rod, weight and weight: 76g ± 0.05g 100g ± 0.05g
4. Weight: 6Kg
5. Dimensions: 280x190x440mm
6. Power supply: AC220V / 50HZ
7. Power: 30W
8. Ambient temperature: ≤35 ℃
