Serve For Real Test
Serve For Real Test
 |
| Place of Origin: | China |
| Brand Name: | SRI |
| Certification: | ISO 9001:2000 |
| Model Number: | TZJ-3 |
| Price: | 700USD/set |
|---|---|
| Packaging Details: | Standard exporting package |
| Delivery Time: | 5-10 working days |
| Payment Terms: | T/T, L/C, PAYPAL |
| Supply Ability: | 100 sets/month |
| High Light: | soil shear test apparatus,soil testing instruments,direct shear test |
||
|---|---|---|---|
Description
This shear apparatus is used to test the soil shear strength, it has two or three speed steps. The specimens are tested under different vertical pressure and applied shear force, thus to obtain the broken shear force.
Technical specifications
Vertical loading: 400KPa, 300KPa, 200KPa, 100KPa, 50KPa
Horizontal loading: 1.2KN
Lever ratio: 1:12
Specimen area: 30cm2
Shear speed: Two speed: 0.8mm/min. 2.4mm/min
Three speed: 0.02mm/min. 0.8mm/min. 2.4mm/min
Power: Two speed: <55W; Three speed: <70W
Power supply: 220V±10% 50Hz
Instrument size: 850 x 550 x 1100mm (L x W x H)
Net weight: 40Kg
