| Place of Origin: | China |
| Brand Name: | SRI |
| Certification: | ISO 9001:2000 |
| Model Number: | TWCX-2 |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | 500USD/set |
| Packaging Details: | Standard exporting package |
| Delivery Time: | 5-10 working days |
| Payment Terms: | T/T, L/C, PAYPAL |
| Supply Ability: | 100 sets/month |
| Power: | Electronic | Usage: | Soil Test |
|---|---|---|---|
| High Light: | Unconfined compression test,soil testing instruments |
||
Description
The unconfined compression testing apparatus is used to determine the cohesive soil mechanical characteristics, it has manual and electro-driven type. This apparatus is comprised of base, jack, bearing plate, proving ring, handle, dial gauge, frame. It's kind of very common soil testing instrument.
Technical parameters
1. Max loading: 5KN
2. Motor power: AC 220V, 50Hz, 170W
3. Electric Lifting speed: 3mm/min
4. Manual lifting speed: 18 circles/1mm
5. Screw rod plate diameter: Ф52mm
6. Sample size: Dia. 50*50mm, Dia. 50*100mm
7. Screw rod move distance: 50mm
Completer with 3pcs dial gauges( 0-10mm/0.01mm 1pc, 0-30mm/0.01mm 2pcs), 1pc proving ring.
