| Place of Origin: | China mainland |
| Brand Name: | SRI |
| Certification: | ISO 9001 |
| Model Number: | DHGP |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | 3000-4000USD |
| Packaging Details: | Polywood case |
| Delivery Time: | 10 working days |
| Payment Terms: | T/T, Western Union, L/C |
| Supply Ability: | 20sets/Month |
| Standards: | GB, ISO, EN | Test Material: | Electronic Products |
|---|---|---|---|
| Customized: | Yes | Power Supply: | AC 220V, 380v, 50HZ |
Features
Material: Internal material made of 1.5t white iron steel plate, external SS41 steel plate with anti-rust treatment and powder baking paint (iron gray)
Insulation: High-density 100K high-temperature-resistant insulation cotton is used. Six sides are insulated.
Door: Single-open door type, American full-open rear button, high-temperature resistant silica gel is installed around the door, which is strong and durable.
Ventilation device: The ventilation volume adopts a full-in, full-out adjustable damper, which can be directly connected to the exhaust pipe.
Machine pulley: move the pulley to adjust the placement position and solid bolt fixing position
In-box tray rack: Two movable tray racks or stainless steel strip grid trays are equipped as standard.
Air supply system: special high temperature (Taiwan made) oven dedicated motor, with multi-wing wind wheel high-speed operation and single-sided horizontal air circulation, uniform temperature.
Electric heating system: It adopts Japanese-made sheathed electric heater (SHEATHED HEATER) dust-free electric heating generator. Low radiant heat is not easy to oxidize, and the durability is 5-10 years.
Insulation device: no fuse switch, over temperature protection switch, porcelain fuse
Accessories: Adjustable partition board 2-6 pieces
Delay power-off function (can be purchased separately with program control)
Fuse device: first time over-temperature alarm, second time over-temperature cut-off function, MCCB overload protection, temperature self-tuning, electric fin-type radiating tube-shaped electric heating tube
Air transport system: Forced air circulation system and specially designed air outlet, excellent temperature uniformity
Control mode: Automatically turn on the timer when temperature reaches, cut off power supply when time reaches, and beep
Specifications
| Model | DHGP-072 | DHGP-270 | DHGP-480 | DHGP-600 | DHGP-720 | DHGP-1000 |
| Internal chamber size (cm) W×H×D | 40×45×40 | 60×90×50 | 80×100×60 | 100×100×60 | 100×120×60 | 100×100×100 |
| Overall size (cm) W×H×D | 72×116×56 | 93×163×67 | 110×172×77 | 130×172×77 | 116×170×116 | 116×150×166 |
| Temperature range | RT+25℃～200℃(300℃) | |||||
| Temperature fluctuation | ±0.3℃ | |||||
| Temperature uniformity | ±1%℃ | |||||
| Temperature readout | 0.1℃ | |||||
| Temperature rise duration | 30min | |||||
| Enclosure material | Cold rolled plate + baking paint | |||||
| Liner material | #201 Stainless steel (when >200℃ # 304 SUS stainless steel used) | |||||
| Insulation material | Glass wool | |||||
| Circulation system | Centrifugal fan air circulation system | |||||
| Heat system | SUS# High speed heater | |||||
| Control system | keypress digital controller | |||||
| Accessories | Control status indicator, compartment shelf (2, height adjustable) | |||||
| Safety device | Phase sequence protection, over temperature, over current, overload | |||||
| Power supply | AC 1Ψ 220V 60/50Hz, AC 3Ψ 380V 60/50Hz | |||||
| Customized | Yes | |||||
