| Place of Origin: | China mainland |
| Brand Name: | SRI |
| Certification: | ISO 9001 |
| Model Number: | PY |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | 3000-4000USD |
| Packaging Details: | Wooden case |
| Delivery Time: | 10 working days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100set per month |
| Disc Dia.: | 175mm | Feeding Size: | <4mm |
|---|---|---|---|
| Output Size: | 0.075mm-0.15mm | Power Supply: | AC380V, 50Hz, 3PH Or Others |
Round disc grinding machine Cement Clinker Ore Disc miller Lab crusher
This machine is mainly used for grinding of cement clinker and ores in laboratories. Features easy operation, high work efficiency, nice appearance. The grinding disc is made of high strength Manganese steel, high hardness, good wearing resistance
This grinding machine is constructed of support, bearing base, grinding base, dynamic grinding disc, fixed grinding disc, flexible grinding cover, belt wheel, motor
Grinding disc dia. 175mm
Max feeding material size: 4mm
Output size: 0.075mm-0.150mm(80-200 mesh)
Production rate: 25kg/hr
Main shaft rotation: 900rpm
Motor Power: 1.1kw
Motor working voltage: AC 380V/460V, 50/60HZ, 3Ph
Overall size: 850*800*650mm
Net weight: 180kg
