| Place of Origin: | Jiangsu |
| Brand Name: | SRI |
| Certification: | ISO9001 |
| Model Number: | JB-300 |
| Price: | 2500-3000 USD/set |
|---|---|
| Packaging Details: | Standard exporting packing |
| Delivery Time: | 5-10 working days |
| Payment Terms: | T/T |
| Supply Ability: | 50set/month |
| Minimum Order Quantity: | 1set |
| High Light: | Pendulum hammer impact testing machine,bob hammer impact testing machine,material impact testing machine |
||
|---|---|---|---|
Model: JB-300
1. Description
This machine is used to test the impact properties of metal material under dynamic loading, it’s of manual control. It’s suitable for ferrous metal with strong roughness. It complies to the GB229-2007 standards 《Metal material Pendulum hammer impact testing methods》.
2. Configuration
1.Main machine: 1 set
2.Pendulum hammer: 150J*1, 300J*1
3.Internal hexagon wrench: S=12, 1pc
4. Support regulator: 1pc
5. Test-piece aligner: 1pc
6. Stripping attachment: 1pc
7. Foundation screw: 4sets
3. Specification
Max impact power | 300 Joule |
Testing range & resolution | 0-300 joule: 2 joule /rule |
Pendulum hammer torque(impact constant) | M300=175.7356 Joule M150=87.8678 Joule |
Pendulum shaft center to test-piece center distance | 800mm |
Pendulum hammer pre-elevation | 135degrees |
Impact speed | 5m/s |
Test-piece support span | 40mm 70mm |
Impact knife included angle | 30degrees |
Impact knife fillet radius | R2.0-2.5mm |
Overall size | 1000*630*1520(mm) |
Weight | 320kg |
