| Place of Origin: | China |
| Brand Name: | SRI |
| Certification: | ISO 9001:2000 |
| Model Number: | XCJ |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | 3000 USD/set |
| Packaging Details: | Polywood case |
| Delivery Time: | 5-10 working days |
| Payment Terms: | T/T, L/C, PAYPAL,Western Union |
| Supply Ability: | 200 sets/month |
Standards
ISO180-2000 "Plastics - Determination of Izod Impact Strength of Hard Materials"
GB/T1843—2008 "Izod Impact Test Method for Rigid Plastics"
JB/T8761—1998 "Plastic Izod Impact Tester"
ASTM D256-2010 "Test Method for Determination of IZOD Pendulum Impact Strength of Plastics"
Description
The IZOD impact testing machine is mainly used to test the IZOD impact strength of nonmetal materials.
Features
The machine adopts semi-automatic control, which is easy to operate and has high work efficiency.
The dedicated LCD screen equipped with this machine can display instant information.
Test result can be printed with built in printer
Technical specifications
| Model | XCJ-5.5H | XCJ-22H |
| Impact speed | 3.5 m/s | |
| Pendulum rammer energy | 1J,2.75J,5.5J | 11J,22J |
| Impact center distance | 335mm | |
| Rammer pre-elevation angle | 150° | |
| Impact blade edge included angle | 75° | |
| Null impact energy loss | <0.5% | |
| Operation temperature | 15℃-35℃ | |
| Power supply | AC220V ,50Hz | |
| Min resolution | 0.001J(<5.5J) | |
| Overall dimension | 550mm×350mm×850mm(L*W*H) | |
| Net weight | 90kg | |
