Place of Origin: | China |
Brand Name: | SRI |
Certification: | ASTM |
Model Number: | HBE |
Minimum Order Quantity: | 1set |
---|---|
Price: | 1500-2000 USD/set |
Packaging Details: | Polywood case |
Delivery Time: | 5-10 working days |
Payment Terms: | T/T, L/C, PAYPAL |
Supply Ability: | 200 sets/month |
Power: | Electronic | Usage: | Hardness Tester |
---|
Description
The electric Brinell hardness tester can test ferrous and non-ferrous metal Brinell hardness, it’s kind of common material hardness tester. It’s loaded by close-loop sensor, controlled by electric system. It features high accuracy, good repeatability and stable performance, easy in operation
Technical specifications
Brinell ruler: HBW2.5/62.5,HBW2.5/187.5,HBW5/125,HBW5/750,HBW10/100,HBW10/250,HBW10/500,HBW10/1000,HBW10/1500,HBW10/3000
Test power:
62.5kgf(612.9N),100kgf (980.7N),125kgf (1226N),187.5kgf (1839N),250kgf 250kgf (2452N),500kgf (4903N),750kgf (7355N),1000kgf (8907N),1500kgf 1500kgf (14710N),3000kgf (29420N)
Max test range: 0.005mm
Max amplification times: 20X
Load keeping time: 5~60S
Overall size: 550×210×750mm(L*W*H)
Main machine weight: Approx 125kg
Specimen Max height: 230mm
Pressure head to wall distance: 135mm
Test range: 8~650HBW
Power supply: AC220V±5%,50~60Hz
Standard accessories
Micro-scope,
Hardened alloy ball pressure head: 2.5,5,10mm
Standard hardness block: 2pcs
Large platform:1pc
Middle platform: 1pc
V type platform: 1pc
Power sully:1set
