Serve For Real Test
Serve For Real Test
 |
| Place of Origin: | China |
| Brand Name: | SRI |
| Certification: | GB, ISO |
| Model Number: | CT-UV |
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | 10000-15000USD |
| Packaging Details: | Standard exporting package |
| Delivery Time: | 15 days |
| Payment Terms: | TT/Paypal/Western Union |
| Supply Ability: | 200Sets/Month |
| Display: | LCD | Controlled By: | MCU |
|---|---|---|---|
| Liner Material: | Stainless Steel | Programmble: | Yes |
Standards
ASTM D4329, ISO 4892-3, ISO 11507, SAE J2020, ASTM D7238, ASTM G154, G155
Features
1. Provide comprehensive and detailed real-time monitoring and curve recording for important test parameters such as irradiance, temperature and time (controller with recorder function), and generate reports and curve printing through computer.
2. Irradiation/condensation/water spray test can be conducted separately, or any combination of irradiation/condensation/water spray test can be programmed.
3. The independently developed industrial level 7-inch true color touch screen control system is adopted, with good stability, monitoring, operability and maintainability.
4. The service life of the imported ultraviolet lamp with expensive materials (the lamp is a consumable, and the service life is about 1600 hours) is provided to facilitate the user to confirm the replacement time of the lamp and save the use cost.
5. The automatic water supply and drainage design is adopted, and the high-power pump with high cost is used to ensure the flow rate and uniformity of water spray.
6. The installation and wiring of the electrical part of the equipment shall comply with the international electrical standards.
Specifications
| Model | CT-UV3-A |
| Equipment function | Lighting, condensation and spraying (three function slicing arrangement) |
| Inner box size | W 114 X H 39 X D 40 cm (W X H X D) |
| Test piece | 75mm * 140mm, 48 pieces |
| Approximate overall dimensions | W 130 X H 148 X D 55 cm (W X H X D) |
| Temperature range | Adjustable at room temperature+10~70 ℃ |
| Humidity range | ≥90%RH |
| Lamps | 8pcs UVA-340 (315~400nm) default configuration, 8pcs UVB-313 (280~315nm) (optional) |
| Lamp brand | US Q-Lab or US ATLAS imported with original packaging (100% compensation for one fake) |
| Center distance of lamp | 70mm |
| Center distance between the test object and the lamp tube: | 50±3mm |
| Irradiation intensity | Adjustable or maximum power output within 0.35~0.9W/m2 (adjustable only if the solar eye online control system is included) |
| Temperature fluctuation | ±3℃ |
| Temperature resolution: | 0.1℃ |
| Blackboard thermometer | 45～80℃; Tolerance: ± 3 ℃ |
| Temperature control mode | PID self-tuning temperature control mode |
| Environmental conditions | When the ambient temperature is+28 ℃, the relative humidity is ≤ 85%, and there is no sample in the test chamber |
