Automated Houillon Viscometer ASTM D7279 oils test equipment

Automated Houillon Viscometer ASTM D7279 oils test equipment

Automated Houillon Viscometer ASTM D7279 oils test equipment

Product Details:

Place of Origin: Jiangsu
Brand Name: SRI
Certification: ISO 9001:2008
Model Number: SY-825

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: 10000-30000USD/Set
Packaging Details: Carrying case
Delivery Time: 15-20 days
Payment Terms: T/T, Paypal
Supply Ability: 100Sets/Month
Contact Now
Detailed Product Description
Standards: ASTM D7279 HS CODE: 9031809090
Category: Oils Test Instrument Warranty: 24 Months

The SY-825 Kinematic Viscosity Tester is specially used to measure the kinematic viscosity of oil products. It is designed and manufactured according to ASTM D7279 standard. It can measure transparent and opaque liquids including crude oil, light and heavy fuel oil, lubricating oil, additives, waste oil, etc.

Test method: when the temperature reaches equilibrium, put the sample into the viscosity tube, and the instrument automatically detects the movement time of the sample, and automatically calculates the experimental results. The experiment of cleaning the viscosity tube is over.



Dual CPU microcomputer control.

It can synchronously measure the kinematic viscosity of four samples and automatically print the results.

Constant temperature, detection, calculation and drying are fully automatic.

Fast measurement speed. The results of a single sample can be produced in 1 minute at the most, generally in 3-5 minutes, and the whole process takes no more than 10 minutes.

It has automatic fault diagnosis program.

LCD display, human body inductive button.

The imported detection module is used for dynamic detection to avoid the phenomenon of missed detection and false detection.

The kinematic viscosity tester is equipped with an oil drain for easy oil drainage.

The kinematic viscosity measurement is completed with one button to simplify the operation.

Infrared liquid level detection is not disturbed by indoor light and light.



Temperature range Room temperature~100 ℃
Control accuracy ±0.01℃
Temperature sensor Imported stainless steel Pt100 temperature probe%
Heating mode Electric heating unit, maximum heating power 1500W, PID control
Liquid level detection Infrared photoelectric detection
Display 7-inch color touch screen
Temperature correction 6-point correction
Test scope 0.5~10000mm2/s
Repeatability 40℃,≤0.68%(6~17mm2/s); 100℃,≤1.6%(25~150mm2/s)
Serial port RS232 interface can be connected to computer or laboratory platform for data processing
Power supply/td> AC220V±10% 50Hz±10%
Operating ambient temperature (10~40)℃
Storage ambient temperature (0~50)℃
Experimental hole 4 holes
Clock display Year, month, day, hour and minute (power off work)



Standard accessories

Curved tube viscometer/detector assembly/pipette/1mL suction nozzle/viscosity reference sample

Attention notes

1. The full-automatic kinematic viscosity tester shall be protected from severe vibration during use or handling.

2. Before using the automatic kinematic viscosity tester, connect all connecting wires completely.

3. In case of any abnormality found during the use of the kinematic viscosity tester, immediately cut off the power supply.

4. Before temperature control, ensure that the oil bath in the oil bath tank is kept near the scale line.

5. When doing the experiment with high temperature, pay attention to avoid touching the oil bath or observation window directly with your hands to prevent scalding.
